STD1000WG (Solar Grid-tie Inverter, 1KW)
STD1000WG (Solar Grid-tie Inverter, 1KW)

1 KW offgrid inverter, with surge power at 2KW.
DC Input: 12V (10-15Vdc), Output: 110VAC, 60 Hz. Safety features and specs - see picture document (global power specs, read the USA ones only, eg 110VAC, not 230VAC).

Our pure sine wave inverter converts Battery DC (12V) to AC (120V, 1000W). Unlike Modified Sine Wave inverters that output square wave and cause a humming noise in stereo equipments and other static issues in AC electronics, pure sine mimics the power grid's power waveform exactly. The statics from modified sine wave may damage your electronics over time. Buy our pure sine wave inverter for trouble-free AC power.

CE Certified. Output: AC 120V, 60Hz.
Size: 11.5 x 6.5 x 3 ins, Weight: 7.6 lbs.
Low Battery Shutdown: 9.7 to 10V DC
High Battery Shutdown: > 15V
Automatic Overload and High Temperature Shutdown

Safety Features of this Inverter

  • Electronic overload protection with automatic shutdown
  • Built-in internal backup DC fuse provides added safety
  • Low battery oltage warning followed by automatic shutdown
  • High input voltage protectio with automatic shutdown
  • Over temperature protection with automatic shutdown
  • Output short circuit protection

Specifications

AC output voltage (nominal) 110 Vac
DC input voltage range 11-15Vdc
AC output frequency 60 +/- 2Hz
AC output waveform Pure Sine Wave
Ambient operating temperature range 32-104F (0-40C)
Low battery alarm trigger range (nominal) 10-10.4V
Low battery shutdown range (nominal) 9.7-10V
High battery shutdown >15V
